Fiber Optic Cold Splice Production

Optical network knowledge brief Published 30 Aug 2024

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

Fiber optic cold splicing joins two optical fibers without fusion, using precise alignment and connectors for quick, low-cost field connections.Overview of Cold Splicing

Fiber optic cold splicing is a method of joining optical fibers without heating or fusing the glass. Instead, the fibers are aligned and held in place using a cold splicer or mechanical connector, often with snap rings or V-grooves to maintain precise alignment . This method is particularly useful for field operations, FTTH (fiber-to-the-home) installations, and situations where fusion splicing equipment is impractical or costly . Cold splices are considered semi-permanent; they provide reliable optical connections but generally have slightly higher insertion loss compared to fusion splices . The main advantages include ease of operation, speed, and low equipment cost, making them suitable for rapid deployment in access networks .

Equipment Required
  • Cold splicer or mechanical connector: Contains a precise V-groove or alignment mechanism to hold fiber ends.
  • Fiber stripper: For removing the protective coating from the fiber.
  • Cutting knife or cleaver: To trim the fiber to the correct length.
  • Alcohol wipes: For cleaning the bare fiber ends to remove dust or oils . Unlike fusion splicing, cold splicing does not require expensive fusion splicers or power sources, making it ideal for field use .
Production Steps
  1. Install the cold connector: Snap the connector into place, ensuring the middle slot and side snap rings are properly engaged.
  2. Prepare the fibers: Strip approximately 3 cm of coating from each fiber end and clean with alcohol.
  3. Cut the fibers: Use a fiber cutter to trim about 1.4 cm of the bare fiber to ensure a clean endface.
  4. Insert fibers into the connector: Place each fiber end into the cold connector, ensuring they are aligned in the V-groove and secured by the snap rings.
  5. Test the connection: Verify optical continuity and insertion loss to confirm a successful splice .
Quality Considerations
  • Alignment precision is critical; misalignment can increase insertion loss or cause reflection.
  • Cleanliness: Dust or oil on fiber ends can degrade performance.
  • Mechanical stability: Properly secured snap rings or clamps ensure the splice remains stable over time .
Applications

Cold splicing is widely used in:

  • FTTH deployments: Quick and cost-effective connections for home installations.
  • Field repairs: Temporary or semi-permanent connections where fusion splicing is impractical.
  • Multimode fiber networks: Often used for temporary restoration or lower-cost installations .
Comparison to Fusion SplicingFeatureCold SpliceFusion SpliceEquipmentSimple, low-costExpensive fusion splicerConnectionMechanical alignmentGlass fusionInsertion LossSlightly higherVery low (0.03–0.05 dB typical)Field UseEasy, fastRequires power and careful handlingPermanenceSemi-permanentPermanent, highly reliable

Cold splicing provides a practical, efficient solution for many field applications, especially where speed, cost, and portability are priorities.
