Specifications and parameters of multi-hole explosion-proof distribution box

Optical network knowledge brief Published 07 Apr 2025

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

Multi-hole explosion-proof distribution boxes, such as HRMD92 and SBOX series, are designed for hazardous areas with customizable configurations, stainless steel enclosures, and compliance with IECEx, ATEX, and GB standards.Key Specifications

Enclosure Material and Protection:

  • Typically made of 316 stainless steel or aluminum alloy with stainless steel fasteners for durability and corrosion resistance .
  • Flameproof design (Ex d IIB+H2 or IIC) suitable for Zone 1 and Zone 2 hazardous areas .
  • Protection ratings: IP66, capable of withstanding dust, water, and high temperatures up to T800°C . Certifications:
  • IECEx, ATEX, GB3836, IEC 60079 series for gas and dust explosion protection . Electrical Components Compatibility:
  • Can house MCB/MCCB, AC contactors, thermal relays, PLCs, soft starters, frequency converters, surge protectors, meters, pushbuttons, indicators, and motor protection switches .
  • Supports multi-site control for motors, including start, stop, corotation, and inversion functions . Multi-hole Design:
  • Side panels can be equipped with multiple entry holes for cable glands or plugs, customizable according to dissipated power and mechanical strength requirements .
  • Standard entry: M ☐ x 1.5 plug, with NPT plug available on request . Installation Flexibility:
  • Can be combined and installed freely to save space and meet various distribution system requirements .
  • Supports hanging, embedded, bracket, or heat tracing installation depending on site conditions .
Popular Models

HRMD92 Series:

  • Stainless steel enclosure with specialized hinge structure to protect flameproof joints .
  • Can include ammeters, voltmeters, power meters, control switches, and other electrical devices.
  • Suitable for motor control, circuit distribution, and remote/local operation.
  • Customizable according to user requirements, including the number of cover components and maximum side holes . SBOX Series:
  • Aluminum alloy or stainless steel enclosures with multiple installation options .
  • Designed for chemical, oil refining, offshore platforms, and military applications.
  • Supports high-power heaters, heat tracing systems, and cable distribution.
  • Models include SBOX0211B, SBOX0311C, with variations in terminal current, incoming/outgoing line direction, and cable gland specifications .
Summary

Multi-hole explosion-proof distribution boxes are highly versatile, durable, and certified for hazardous environments. They allow customized configurations for electrical components, flexible installation, and safe energy distribution. Models like HRMD92 and SBOX provide options for stainless steel or aluminum enclosures, multiple entry holes, and advanced motor and circuit control capabilities, making them suitable for industrial, chemical, and offshore applications .
