Optical power of the optical module

Optical network knowledge brief Published 10 Apr 2023

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

The optical power of an optical module refers to the intensity of light emitted by its transmitter or received by its receiver, typically measured in dBm.Definition and Types of Optical Power

Transmit optical power is the optical intensity output by the module's transmitter (laser diode or LED) under normal operating conditions. It represents the strength of the optical signal sent into the fiber and is often expressed as average optical power, measured in watts (W), milliwatts (mW), or decibels-milliwatts (dBm) depending on the context . The actual power can vary with the data pattern, as more "1"s in the signal generally produce higher optical power. Receive optical power refers to the optical signal intensity that the module's receiver can detect and process. It is defined as the range of optical power that the receiver can handle while maintaining a specified bit error rate (BER), usually 10^-12 . This includes:

  • Receiver sensitivity: the minimum optical power the receiver can detect reliably. A lower minimum receive power indicates better sensitivity.
  • Overload optical power (saturated optical power): the maximum optical power the receiver can safely handle without signal distortion or damage. Exceeding this power can saturate the photodetector, reduce sensitivity, and cause bit errors .
Measurement and Units

Optical power is commonly measured in dBm, a logarithmic unit relative to 1 milliwatt, which allows easy comparison of signal levels in fiber-optic systems. Linear units like mW or W are also used, especially in laboratory measurements .

Importance in Optical Communication

The optical power of a module is critical for ensuring reliable data transmission. Proper transmit power ensures the signal can travel the required distance without excessive attenuation, while appropriate receiver sensitivity and overload limits prevent errors and protect the module from damage . In summary, the optical power of an optical module defines both the strength of the transmitted light and the range of light intensities the receiver can handle, making it a key parameter for the design and operation of fiber-optic communication systems.
