How to manufacture cable tray cover plates

Cable tray cover plates can be fabricated from sheet metal, cut to size, drilled for fasteners, and installed to protect and secure cables.Materials and Tools

• Material: Use sheet metal such as galvanized steel, aluminum, or PVC depending on environmental conditions and load requirements .
• Tools: Metal shears or saw, drill with appropriate bits, deburring tool, measuring tape, marker, bending brake (for flanged edges), and fasteners (bolts, nuts, or self-tapping screws), .

Fabrication Steps

1. Measure the Tray: Determine the width and length of the cable tray to ensure the cover plate fits flush over the tray edges .
2. Cut the Sheet: Cut the sheet metal to the measured dimensions, allowing for flanges on the sides to secure the cover to the tray.
3. Bend Flanges: Use a bending brake to create flanges along the edges of the cover plate. Flanges typically range from 0.5 to 1 inch to provide a secure attachment point .
4. Mark and Drill Holes: Align the cover plate over the tray and mark the locations for fasteners. Drill clearance holes through the flanges to match the tray's side rails. Standard hole sizes are often 3/8” or 1/4” depending on the fasteners used .
5. Deburr Edges: Smooth all cut and drilled edges to prevent injury and avoid damaging cable insulation.

Installation

• Align the Cover: Center the cover plate over the tray, ensuring it is flush with the tray edges .
• Secure Fasteners: Attach the cover using bolts and nuts, or self-tapping screws through the drilled holes. Torque fasteners according to the tray manufacturer's specifications (e.g., 3/8” bolts to 19 ft-lbs), .
• Check Stability: Ensure the cover is firmly attached and does not move under light pressure. Proper installation prevents cable damage, maintains system stability, and allows for easy maintenance .

Additional Considerations

• Ventilation: For ventilated trays, consider perforating the cover to allow airflow while still protecting cables .
• EMI/RFI Shielding: Solid covers can provide electromagnetic interference protection for sensitive circuits .
• Outdoor Use: Drill weep holes in solid covers to prevent water accumulation if installed outdoors or in humid environments .
• Compliance: Follow local electrical codes and NEMA standards for cable tray systems to ensure safety and reliability . By following these steps, you can fabricate and install cable tray cover plates that are durable, safe, and compliant with industry standards.
