Commonly used models of optical power meters include

Optical network knowledge brief Published 07 Feb 2023

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

Optical power meters are available in a wide range of models from multiple manufacturers, covering handheld, rack-mounted, and inline configurations for various wavelength ranges and power levels.Major Optical Power Meter Models and Series

Quantifi Photonics

  • Power 1400 Series: Fast monitoring from -60 to +10 dBm, wavelength range 750–1700 nm, logarithmic amplifier for stable readings .
  • Power 1410: High-density, up to 288 parallel channels in 1U rack-mountable form .
  • Power 1500 Series: Logarithmic analog output, ideal for active fiber alignment .
  • Power 1600 Series: Inline monitoring from -50 dBm to +20 dBm, 1–4 channels, compact form factor . Fluke Networks
  • SimpliFiber® Pro Optical Power Meter: Handheld, first-line fiber testing, supports PON signals . PRONTO Series
  • PRONTO-250-FLEX: Measures 0.5 W to 250 W, low noise, high damage threshold .
  • PRONTO-SI: Very low power measurements down to 0.3 nW . Thorlabs
  • PM100, PM200, PM300 Series: Touch-screen consoles, compatible with multiple sensor heads, suitable for lab and industrial applications . UT385 Laser Power Meter
  • Measures energy output of laser beams, suitable for testing and laser system applications . Santec
  • Offers a comparison chart of models with electrical/mechanical specifications and form factors for lab and field use . Other Notable Manufacturers and Models
  • M2 Optics Inc.: Custom fiber network testing solutions .
  • L-com: Optical power meters integrated with RF and fiber solutions .
  • Novanta Photonics: Laser-based diagnostic and micromachining equipment with integrated power meters .
  • EXFO: Lab and field network testing tools including optical power meters .
  • Promax Test & Measurement SLU: Telecommunication instrumentation including optical power meters .
  • Sanwa Electric Instrument Co., Ltd.: Digital and analog optical power meters for industrial and lab use .
Key Features to Consider
  • Sensor Type: Photodiode (Si, Ge, InGaAs), thermopile, pyroelectric.
  • Wavelength Range: Typically 750–1700 nm for fiber-optic applications.
  • Power Range: From picowatts to hundreds of watts depending on application.
  • Form Factor: Handheld, rack-mounted, inline, or integrated with laser systems.
  • Applications: Telecom network testing, laser manufacturing, medical laser maintenance, laboratory experiments. This list provides a comprehensive overview of optical power meter models and manufacturers, suitable for selecting devices based on measurement range, wavelength, and application requirements .
