How to connect fiber optic splice boxes and terminal boxes

Optical network knowledge brief Published 12 Sep 2023

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

Fiber optic splicing involves joining fibers using fusion or mechanical methods, while terminal and splice boxes organize, protect, and route fibers for reliable network connections.Understanding the Boxes

Fiber optic termination boxes (also called terminal boxes or optical distribution frames) are used to terminate incoming fibers, connect them to patch cords, and provide organized access for end devices like ONUs in FTTH setups. They protect fibers, maintain bend radius, and allow for labeling and future expansion . Fiber optic splicing boxes (splice closures) are designed to join two or more fiber cables, creating a continuous optical path. They house fusion or mechanical splices and protect them from environmental factors like moisture, dust, and mechanical stress .

Preparing for Splicing
  1. Inspect and clean tools: Ensure cleavers, fusion splicers, and mechanical splice kits are clean and calibrated .
  2. Strip the fiber: Remove the protective coating carefully without damaging the glass core.
  3. Organize fibers: Use splice trays or modules to manage slack and maintain minimum bend radius (typically 30 mm for G.657 fibers), .
Splicing Methods

Fusion Splicing:

  • Align fiber ends precisely using a fusion splicer.
  • Apply an electric arc to fuse the fibers, creating a permanent, low-loss connection (typically
