Optical power meter including light source

Optical network knowledge brief Published 17 Apr 2024

Prepared for preliminary research by the COETZER OPTICAL knowledge desk. Confirm compatibility, loss budgets and installation requirements against current standards and product documentation.

An optical power meter combined with a light source, often called an Optical Loss Test Set (OLTS), measures optical power and fiber link loss efficiently in both field and lab environments.Overview

An optical power meter (OPM) measures the power of an optical signal, typically in fiber optic systems, using a calibrated photodiode sensor, amplifier, and display. When paired with a light source, the system can measure end-to-end optical loss, making it ideal for testing fiber links, insertion loss, and network performance. This combination is commonly referred to as an Optical Loss Test Set (OLTS) and may also measure optical return loss in advanced models (Wikipedia) .

Key Features
  • Wavelength Support: Combined units often support multiple wavelengths, such as 850, 980, 1270, 1300, 1310, 1490, 1550, 1577, 1625 nm, covering both single-mode and multimode fibers (Tempo Communications, Anritsu) .
  • Portability: Many devices are handheld or compact, designed for field use in FTTH, enterprise, carrier, and cable TV networks. They are rugged, durable, and user-friendly, with pre-configured tests for quick measurements (Yokogawa, AFL) .
  • Accuracy: High-precision sensors ensure reliable measurement of optical power and insertion loss. Some models feature auto-zeroing, tone detection, and multi-wavelength calibration for efficient testing (Anritsu CMA5) .
  • Applications: Installation, commissioning, maintenance, and troubleshooting of fiber optic networks. They allow technicians to verify link performance, detect faults, and ensure compliance with network specifications (Yokogawa, Tempo Communications) .
Examples of Combined Devices
  • Tempo Communications OPM/SLS Kits: Offer dual or triple wavelength light sources and optical power meters for accurate insertion loss measurements. Ruggedized and IP54 compliant for field use .
  • Anritsu CMA5 Series: Handheld light source and power meter units supporting multiple wavelengths for single-mode and multimode fibers, suitable for datacom, WDM, and FTTx testing .
  • AFL Contractor Series: Palm-sized optical light source and power meter kits for field testing, capable of measuring insertion loss and optical power across multiple network types .
Advantages of Integrated Systems
  • Efficiency: Simultaneous measurement of optical power and loss reduces testing time.
  • Ease of Use: Pre-configured tests and auto-wavelength matching minimize errors.
  • Versatility: Suitable for a wide range of fiber networks and testing scenarios.
  • Portability: Lightweight and rugged designs allow field technicians to perform reliable measurements in various environments. In summary, optical power meters with integrated light sources provide a complete solution for fiber optic testing, combining accurate power measurement with the ability to assess link loss, making them essential tools for both field and laboratory applications.
