What is the use of the OLS interface on an optical power meter

The OLS interface on an optical power meter is used to connect an Optical Light Source, enabling precise measurement of optical power and fiber link loss.Function of the OLS Interface

The OLS (Optical Light Source) interface allows the optical power meter (OPM) to receive a controlled, stable light signal injected into the fiber under test. The OLS generates a continuous wave (CW) of light at a specific wavelength, which is critical for accurate testing of fiber optic links . By connecting the OLS to the OPM, the meter can measure the amount of light arriving at the far end of the fiber, enabling calculation of the total optical loss or attenuation of the link .

How It Works
  1. Signal Injection: The OLS injects a known, calibrated optical signal into the fiber at a defined wavelength, typically matching the operational windows of the fiber (e.g., 1310 nm or 1550 nm for single-mode fibers, 850 nm or 1300 nm for multimode fibers), .
  2. Power Measurement: The OPM, connected via the OLS interface, measures the received optical power at the far end of the fiber .
  3. Loss Calculation: The difference between the transmitted power (from the OLS) and the received power (measured by the OPM) is used to calculate the attenuation of the fiber link, which is essential for verifying installation quality and ensuring sufficient power margin for network operation .
Importance in Fiber Testing
  • Accuracy: The OLS provides a stable and precise light source, which is necessary for reliable power measurements and consistent results .
  • Certification: Using the OLS interface with an OPM forms the basis of Tier 1 certification testing, ensuring that fiber links meet industry standards for optical loss .
  • Wavelength Matching: The interface allows testing at multiple wavelengths, which is important because fiber attenuation varies with wavelength. Dual-wavelength OLS units enable testing at both 1310 nm and 1550 nm without changing equipment . In summary, the OLS interface on an optical power meter is essential for connecting a calibrated light source, allowing the meter to measure received optical power accurately and calculate fiber link loss, which is critical for network verification, certification, and troubleshooting.
